1) X선 발생부 :  micro focus  X-ray Generator 80kV

 2) X선 검출부 :  1K x 1K , 48um pitch,
          FOV :  50mm x 50mm ( 100mm x 50mm )
          Variable Magnification

 3) Shield Cabinet ( 600(W) x 600(D) x 800(H) (mm))
                                 차폐 : 1uSv/h or less

 4) Computer : Intel Dual Core Xeon 3.0GHz,
     RAM : 2GB, 300G HD x 2EA 20", 1600 x 1200 LCD


5) Softwares :
    System Operating S/W

 6) Imaging Viewer
 - Brightness/Contrast variation, Magnification, Profile
 - Measurement : Length and Area at any Magnification
